Marine Seawater Desalination

Seawater Desalination SystemSeawater Reverse Osmosis (SWRO) Desalination System for use on marine vessels

JHH-FSHB series marine watermakers are designed for seawater desalination. We are able to provide a large and diverse range of desalination systems for any application, such as water vessels, cruise ships, commercial boats, offshore drilling platforms, etc.

Our RO system can produce safe drinking water by eliminating the harmful effects of heavy metals, bacteria, etc. since the system employs a semipermeable membrane that separates an extremely high percentage of unwanted molecules. With no chemicals added in the whole process, the drinking water entirely conforms to the Guidelines for Drinking Water Quality released by WHO and National Standards for Drinking Water Quality.

JHH-FSHB series marine watermakers are made of seawater corrosion resistant materials to guarantee the quality of the output water and extend its service life. For example, dual-phase steel is used in the high pressure components, and UPV is used in the low pressure parts.

Features:

Fully automatic configuration with 'one touch' operation makes it very convenient to operate and maintain.
Equipped with an automatic alarm system. It will automatically alarm and diagnose the problem if any fault occurs.

Specs:

Inflow salinity≤38000ppm
Desalindemation rate≥98%
Inflow temperature 2~40℃
Production: 1~80ton per day

Optional Models

Model	Output capacity (m³/h)	Operational pressure(Mpa)		Electric source		Dimension(mm)	Construction
Model	Output capacity (m³/h)	Pre-treatment	Membrane	Voltage(V)	Power (kW)	Dimension(mm)	Construction
JHH-FSHB1	0.05	0.1-0.3	4-6.5	220/380	1.5	580×440×1600	Vertical
JHH-FSHB2	0.1	0.1-0.3	4-6.5	220/380	1.5	580×440×1600	Vertical
JHH-FSHB3	0.15	0.1-0.3	4-6.5	220/380	1.5	580×440×1600	Vertical
JHH-FSHB5	0.25	0.1-0.3	4-6.5	220/380	2.2	650×440×1600	Vertical
JHH-FSHB10	0.5	0.1-0.3	4-6.5	380	4.5	950×600×1800	Vertical
JHH-FSHB20	1	0.1-0.3	4-6.5	380	7.5	2500×700×1200	Horizontal
JHH-FSHB50	2.5	0.1-0.3	4-6.5	380	22	2500×1200×1700	Horizontal
JHH-FSHB100	5	0.1-0.3	4-6.5	380	40	3400×1500×1800	Horizontal
JHH-FSHB200	10	0.1-0.3	4-6.5	380		3400×2000×1800	Horizontal

JHH is a seasoned manufacturer of commercial water purification systems and equipment. We innovate, design and manufacture state of the art seawater reverse osmosis systems, wastewater treatment systems and water purification systems for onshore and offshore applications. From isolated islands to drought prone areas, from coastal to desert environments, we provide custom engineered solutions to suit different water treatment demands around the world. We are capable of completing a turn-key seawater desalination plant or water purification plant with our quality workmanship, professional technical service and satisfied after-sale support. We welcome all questions regarding our products, please feel free to connect with us for an initial consultation.

Send an Inquiry

JHH began manufacturing seawater desalination equipment and water treatment system in the early 2002. We are committed to meeting or exceeding your needs on seawater desalination and water purification equipment. Our water desalination systems use advanced reverse osmosis (RO) seawater desalination technology to help our customers achieve high water filtration performance with lower operation cost. No matter your projects require marine vessel installations or land based applications, JHH will strive to provide you with custom-engineered turn-key solutions complied with your local regulatory requirements of water treatment.
